Man Overboard waypoint
If an emergency situation should occur, you can save a Man Overboard (MOB) waypoint at
the vessel’s current position.
Create a MOB
To create a Man Overboard (MOB) waypoint:
Select the MOB button on the Home page
Press the MOB key on a remote controller
Press and hold the F12 key on a keyboard
When you activate the MOB function, the following actions are automatically performed:
A MOB waypoint is created at the vessel’s position
The display switches to a zoomed chart panel, centered on the vessel's position
The system displays navigation information back to the MOB waypoint
Multiple MOB waypoints can be created. The vessel continues to show navigation
information to the initial MOB waypoint. Navigation to subsequent MOB waypoints needs to
be done manually.
Delete a MOB
A MOB waypoint can be deleted from the menu when the MOB is activated.
Stop navigating to MOB
The system continues to display navigational information towards the MOB waypoint until
you cancel the navigation from the menu.
Application pages
A Home/pages button
B Application panel
C Menu button
D Instrument bar
E Control bar
Application panels
An application panel shows the application and provides a menu with customize options.
The application panels and the menu options are further explained in each application
chapter in this manual.
Predefined split pages
A predefined split page shows more than one application page on a panel.
You can adjust the split on a predefined split page. Refer to "Adjusting the split on multiple panel pages"
on page 19.
Introduction | NSO evo3S MPU Operator Manual
13
