Trolling motor speed control

In Heading lock mode, Nav. mode and in Turn pattern steering the autopilot system can

control the trolling motor speed.

The set target speed is displayed in the autopilot controller.

There are two ways to control the target speed of the trolling motor:

• Propeller rate, set as a percentage of power (A)

• Cruise control speed (B)

Switch between the speed options by selecting the speed icon.

The speed is increased/decreased in preset steps by selecting the plus and minus buttons.

The speed can also be set manually by selecting the speed field (C).

Recording and saving a track

A track can be saved as a route from the autopilot controller. If track recording is disabled, the

function can be enabled from the autopilot controller.

For more information, refer to "Waypoints, routes, and tracks" on page 37.

Autopilot settings

Chart compass

Select to display a compass symbol around your boat on the chart panel. The compass

symbol is off when the cursor is active on the panel.

Select active autopilot

Selects if the autopilot controls the trolling motor or the outboard motor(s).

Auto hide autopilot bar

Controls whether the autopilot information bar is shown when the autopilot is in standby.

Arrival mode

The autopilot switches from navigation mode to the selected arrival mode when the vessel

reaches the destination point.

Standby

Disengages the autopilot. The trolling motor is controlled by hand-held remote or by foot

pedal.

Heading lock

Locks and maintains the last vessel heading.

Anchor

Anchors the vessel at the destination point.

Anchor point setup

The trolling motor can store a number of anchor points, labelled with MTG prefix. Anchor

points in the trolling motor are displayed in the Anchor point dialog.

These MTG anchor points can be saved as a waypoint in the MFD system. The position of an

MTG anchor point can be redefined to be identical to an existing waypoint, or to the current

vessel position.

Trolling motor autopilot| NSO evo3S MPU Operator Manual

105
