Simrad NSO evo3S MPU User Manual

If Loran is enabled in the Navigation settings dialog, there are two position panels. This is
indicated with arrow symbols on left and right side of the panel.
You toggle between the panels by:
• selecting the left or right arrow symbols
GPS position info Loran position info
Use menu options
You can use menu options to:
• navigate to a waypoint
• navigate a route
While navigating, the menu expands to provide options to:
• skip waypoints when navigating a route
• restart navigating to a waypoint or a route
• cancel navigating to a waypoint or a route
Navigating with the autopilot
When you start navigation on a system with autopilot functionality, you are prompted to set
the autopilot to navigation mode.
Ú
Note: The prompt to set the autopilot to navigation mode is disabled if the boat type is
set to SAIL in the Autopilot Commissioning dialog.
If you choose not to engage the autopilot, the autopilot can be set to navigation mode from
the Autopilot Controller later on.
For more information about autopilot functionality, refer to the autopilot chapter of the
autopilot being used.
Navigation settings
Navigation method
Different methods are available for calculating the distance and bearing between any two
geographical points.
Navigating | NSO evo3S MPU Operator Manual
43

Simrad NSO evo3S MPU Specifications

General

Video Output	2 x HDMI
Connectivity	Wi-Fi, Bluetooth
Operating System	Linux
Ethernet Ports	2
USB Ports	2
Operating Voltage	12/24V DC
Power Supply	12/24V
