Simrad NSO evo3S MPU User Manual

Maintenance
Preventive maintenance
The unit does not contain any field serviceable components. Therefore, the operator is
required to perform only a very limited amount of preventative maintenance.
Checking the connectors
Push the connector plugs into the connector. If the connector plugs are equipped with a
lock or a position key, ensure that it is in the correct position.
Touchscreen calibration
Use the system setting option to calibrate the touchscreen.
Software updates
Before initiating an update to the unit, be sure to back up any potentially valuable user data.
Refer to "Backing up your system data" on page 139.
Installed software and software updates
The about dialog shows the software version currently installed on this unit (A).
If the unit is connected to internet, the dialog also shows available software updates (B).
Update the software when connected to internet
If the unit is connected to internet, the system will automatically check for software updates
for the unit and for connected devices.
Ú
Note: Some software update files might be larger than the space available in the unit. If
so, you will be prompted to insert a storage device.
Ú
Note: Do not add software update files to a chart card.
Ú
Note: Do not turn off the unit or a remote device until the update is completed, or until
you are prompted to restart the unit.
You will be notified if new software updates are available. You can also manually start the
update(s) from the Updates dialog.
28
Maintenance| NSO evo3S MPU Operator Manual
137

Simrad NSO evo3S MPU Specifications

General

Video Output	2 x HDMI
Connectivity	Wi-Fi, Bluetooth
Operating System	Linux
Ethernet Ports	2
USB Ports	2
Operating Voltage	12/24V DC
Power Supply	12/24V
