1 pc sensor unit
Figure 34 SENSOR-UNIT 13500310
Figure 35 FL-MOTHERBOARD
Table 21 FL-MOTHERBOAR ITEM NUMBERS
1. 13500320 For FL15-02-XXX For FL50-01-XXX
2. 13500321 For FL15-04-XXX For FL100-01-XXX
3. 13500322 For FL15-06-XXX
4. 13500323 For FL15-08-XXX
5. 13500324 For FL15-10-XXX
