FMON10JEN 07.04.2017 Rev. 10J
66 (66)
Table 23 SKF Flowline monitor FL 50 and FL100, parts
1. Body 8. Flow valve shaft
2. Flowtube assembly 9. PTFE ring
3. Position sign 10. Grooved ring
4. Sensor unit B 11. Ring 23,5x1
5. Flowtube 12. Locking ring
6. Flow valve 13. Laminator FL-50
7. O-ring 15,3x2,4 14. Laminator FL
SKF Flowline monitor FL50, exploded view
