Section 02 LUBRICATION AND MAINTENANCE
Subsection 01 (LUBRICATION AND MAINTENANCE CHART)
02-01-4 MMR2000_115_02_01A.FM
Reinstall the spark plug.
NO. 4 – FUEL STABILIZER
A fuel stabilizer (P/N 413 408 600) can be added in
fuel tank to prevent fuel deterioration and avoid
draining fuel system for storage. Follow manufac-
turer’s instructions for proper use.
If above fuel stabilizer is not used, drain fuel sys-
tem including fuel tank and carburetor.
CAUTION: Fuel stabilizer should be added pri-
or the engine lubrication to ensure carbure-
tor(s) protection against varnish deposit.
NO. 5 – FUEL FILTER
REPLACEMENT
Drain fuel tank.
Remove fuel line grommet from fuel tank and pull
out inlet fuel line from tank.
1. Fuel filter
2. Fuel hose
Replace fuel filter.
NO. 6 – FUEL STRAINER
Turn off fuel valve.
FUEL VALVE TO “OFF” POSITION
Remove the strainer cup, as shown in the next
photo.
REMOVE STRAINER CUP
1. O-ring
2. Strainer cup
Clean the strainer cup with cleaning solvent (P/N
413 708 200).
Reinstall strainer cup with O-ring and tighten to
4N•m (36 lbf•in).
WARNING
This procedure must only be performed in a
well ventilated area. Do not run engine during
storage period.
A31I03A
1 2
A31C06A
A31C0NA
1 2
