SMA CLUSTER CONTROLLER User Manual

Status configuration
Symbol Explanation
Corresponds to the value "Logical 1" (= 24V)
Corresponds to the value "Logical 0" (= 0V)
4.2.4.6 Events Menu
In the menu Events, ClusterController events or inverter events in the system are displayed in the
form of an event log. The ClusterController requests the events list from the inverters directly. The
events displayed in each case depend on the inverter that is selected in the system tree, on the user
group, and on the filter settings for the event types (Information, Warning, Error).
Event Types
Symbol Designation Explanation
Error
The Error event has existed for some time and
could not yet be remedied.
Incoming error
An Error event has occurred.
Outgoing error
The Error event no longer exists.
Warning
The Warning event has existed for some time
and could not yet be automatically remedied.
Incoming warning
The Warning event has occurred.
Outgoing warning
The Warning event no longer exists.
Information
The Information event has existed for some
time.
Incoming information
The Information event has occurred.
Outgoing information
The Information event no longer exists.
Severity of the Event
Symbol Explanation
This event can only be rectified by a user with Installer rights (see Section9.1,
page51).
This event can only be rectified by SMA Service (see Section9.1, page51).
4 User Interface of the Cluster Controller
SMA Solar Technology AG
User Manual 31ClusterController-BA-en-15

SMA CLUSTER CONTROLLER Specifications

General

Data Logging	Yes
Display	LCD
Power Supply	24 V DC
Remote Monitoring	Yes
Protection Class	IP20
Communication Interfaces	Ethernet
Product Type	Controller
Manufacturer	SMA
