4.2.4.7 Update and Save Menu
In the menu Update and save, you have the following options:
Parameter group Option
Update Perform an update for the ClusterController via the user inter-
face (see Section14, page73).
Device configuration Save or restore the device configuration of the ClusterCon-
troller (see Section7.4, page42)
Modbus Update or save the Modbus profiles or system configurations
(see Section12.2, page60)
4.2.4.8 Parameter Groups of the Menus
Depending on whether you have selected the system view or the device view in the system tree,
either the parameters of entire device classes or the parameters of the selected device will be
displayed in the parameter groups. The parameter groups that are displayed in the menu and the
information contained in the parameter groups depend on the devices available in the system or
the device selected in the system tree.
Symbol Designation Explanation
Status General information on device status
Type label All values that identify the device/system
Settings Update settings
Device Values that directly affect the device and that
cannot be assigned to any of the other parame-
ter groups (e.g. DC side)
User rights All values that affect access to the device or the
system
DC side Values that affect the DC side of the inverter or
the system
AC side Values that affect the AC side of the inverter or
the system
Grid monitoring Information that affects the utility grid and is par-
tially protected by the personal
SMAGridGuard code
System communication Values that define the communication between
the communication devices and the system, as
well as information on the update status of the
device
