Symbol Designation Explanation

Error

At least one device in the system has the status Fault.

There is a problem with this device that could not be elimi-

nated yet.

Communication error The device cannot communicate at present. This can hap-

pen at night, for example, when the inverter is not feeding

in. This symbol will also be displayed if you have decom-

missioned the device, e.g. for replacement.

To remove the device from the system tree, select [Re-

move] (for information on replacing the ClusterController

or an inverter in the ClusterController system, see the In-

stallation Manual ""Replacement of SMA Devices in Sys-

tems with Communication Products"" at www.SMA-Solar.-

com. ).

4.2.4 Device Menu

4.2.4.1 Overview Menu

Depending on whether you have selected the system view or the device view in the system tree, the

menu Overview displays the most important information on the overall system or on the selected

device.

When a device is selected in the system tree, the yield and output values of that device are also

displayed in four diagrams on the overview page.

Selecting power values for specific times or intervals

Action, button or symbol Explanation

Use the mouse to point at or click on a

part of the diagram sequence

Display the exact power value of the selected part, the

corresponding time and the date

Browse to the previous time period for power values

Browse to the next time period for power values

Directly select the time period for the power values

4 User Interface of the Cluster Controller

SMA Solar Technology AG

User ManualClusterController-BA-en-1526
