Line Explanation

2 Empty line

3 Name of device (serial number or changed device

name)

4 Device type

5 Serial number of the device

6 Name of the values

7 Type of the values

8 Date and time format Value unit

9 Time (= date and time) when the

device generated the value.

Value

10 ... ...

8.2.2 XML Format

If the XML format is selected, the ClusterController creates a directory for each day and saves the

collected system data to this directory every five minutes as XML files. Every 15minutes, the XML

files are packaged to a ZIP file containing threeXML files.

Directory path and structure of the file name

Directory path: .../XML/[YYYY]/[MM]/[YYYYMMDD]/

Structure of the file name for an individual XML file: [HHMMSS].xml

Structure of the file name for a ZIP file: [HHMMSS].zip

Example: daily report file from 2012-10-15, 09:48:02 a.m.

.../XML/2012/10/20121015/094802.xml

8 Exporting System Data

SMA Solar Technology AG

User Manual 45ClusterController-BA-en-15
