CHAPTER 3
USING YOUR INTERACTIVE WHITEBOARD SYSTEM
15 smarttech.com/kb/170549
Setting Use Notes
Aspect Ratio Adjusts the image output to
FillScreen, MatchInput or
16:9.
The default is FillScreen.
FillScreen produces an image that fills the
entire screen by stretching and scaling the
source video to match the projector’s native
resolution and aspect ratio.
MatchInput displays the source video in its
native resolution and aspect ratio. As a result,
unused space could appear along the top
and bottom edges of the screen (letterbox
format) or along the left and right edges of
the screen (pillarbox format).
See Video format on page77 for
descriptions of each mode.
Startup Screen Selects the type of startup
screen (SMART, Capture User
Startup Screen, Preview
Startup Screen), or Image
Alignment Screen.
This screen displays when the projector lamp
is starting and a video source signal isn’t
displayed.
SMART displays the default SMART logo on
a blue background.
Capture User Startup Screen closes the on-
screen display menu and captures the entire
projected image. The captured image is
displayed the next time the on-screen display
opens. (The capture can take up to one
minute, depending on the complexity of the
background graphic.)
Preview Startup Screen enables you to
preview the default or captured startup
screen.
Image Alignment Screen enables you to
adjust the projected image size, shape and
location.
Alignment
Screen
Enables you to adjust the
projected image size, shape
and location.
The image alignment screen appears the first
time you start your projector. However, you
can access it from the startup screen menu
any time. Press Menuor Enter to close it.
Network menu
Network and
VGAOut
Activates the projector’s RJ45
(8P8C) connector and network
features.
