The individual elds on this screen are dened as follows:
Field Name Description
Name A free form text eld. Enter an intuitive name for your cong.
Enable Dropdown selection for either enable or disable of a given QoS queue congured on cho-
sen Layer 2 interface.
Note: Only one queue can be dened for any one interface/precedence pair, resulting in a
maximum of three queues per interface.
Interface Dropdown selection for desired Layer 2 interface to be associated with the dened QoS
queue (e.g. eth0,…eth4).
The following selections are exposed upon dening an Interface as described above:
Queue Precedence Dropdown selection for priority value to be associated with QoS queue dened (e.g. 1(SP),
2(SP), 3(SP), 4(SP|WRR|WFQ)).
Note: Lower value = higher priority
Exposed only if SP|WRR|WFQ Queue Precedence priority as dened above is selected.
Scheduler Algorithm Algorithms for data priority in queue:
[Strict Priority] Allows shaping of rate and burst size for packets in queue.
[Weighted Round Robin] Applies a fair round robin scheme weighting effective for e.g.
ATM networks with xed packets size.
[Weighted Fair Queuing] Applies a fair queuing weighting scheme via allowing different
sessions to have different service shares for improved data packets ow in networks with
variable packets size e.g. PTM/IP networks.
The following selections are exposed only if Strict Priority is selected as Scheduler Algorithm with Queue Precedence of
SP|WRR|WFQ.
Minimum Rate [1-100000 Kbps] [-1 value indicates no minimum shaping applied]
Minimum shaping rate dened for packets in QoS queue.
Shaping Rate [1-100000 Kbps] [-1 value indicates no minimum shaping applied]
Shaping rate dened for packets in QoS queue dened.
Shaping Burst Size [1600 bytes or greater] Shaping dening specic burst size to be applicable to packets in
queue dened.
