- 12 -
No.EX※※-OMW0011-B
1.2. Structure
No. Components Function
1
SI Unit
Fieldbus, valve interface and supply voltage to modules
2
IO-Link Module
Communicate and control to IO-Link devices
3
Digital Input Module
Supply voltage to sensors and input digital data
4
Digital Output Module
Output to electric loads
5
End plate
End plate of module side
6
Solenoid valves
Operate pneumatic devices
Fig. 1-1 System structure
