11.4. Joint pack
One "Joint assembly" and two "Modular adaptor assembly" are contained in one "Joint pack".
Model No.: EX245-ZJP
Joint assembly Modular adaptor assembly
Fig. 11-7 EX245-ZJP
NOTE
・ One Joint pack is attached to the EX245-DX1, EX245-DY1, EX245-LA1 / LB1 and
EX245-EA2-1/2/3/4/5.
・ Regarding mounting, refer to Section 3.1.2
.
