8.5. LED indicators
The status indicators are arranged on the EX245-DY1 as shown in the illustration below.
0 to 7
Description
OFF
Output is not activated and no errors.
Green ON
Output is activated.
Red ON
Short circuit is detected.
Fig. 8-2 Status indicators of the EX245-DY1
