11.3. Seal cap
Model No.: EX9-AWTS
(10 pieces for M12 socket connectors)
The EX9-AWTS can be used with the EX245-SPN3A, EX245-DX1, EX245-DY1 and EX245-LA1 /
LB1.
Mount the seal cap in the unused sockets.
IP65 rating is maintained by using the seal cap properly.
Fig. 11-4 EX9-AWTS
NOTE
・ Tighten the seal caps to the tightening torque specified (0.2 N•m)
・ In case of the EX245-SPN3A, M12 Seal caps is fitted to PROFINET connection Port2 (XF2)
when shipped from factory.
