SMC Networks EX245-EA2 Series User Manual

- 57 -
No.EX※※-OMW0011-B
9.2. Specifications
Table. 9-1 EX245-LA1 / LB1 specifications
Item
Description
EX245-LA1
EX245-LB1
General
Dimensions (W x L x H) in mm
54 x 120 x 61
Weight
265 g
Housing material
Nylon, PBT
Electrical
Rated supply voltage
24 VDC
Internal current consumption
at 24 V DC
50 mA or less
Max. supply current
Device power supply (L+)
0.5 A / Connector
(2 A / module)
0.5 A / Connector
(1 A / module)
Max. supply current
External power supply (P24)
-
1.6 A / Connector
(3 A / module)
IO-Link
IO-Link version Version 1.1
IO-Link port class
Class A
Class B
Communication speed
COM 1 ( 4.8kpbs)
COM 2 ( 38.4kpbs)
COM 3 (230.4kbps)
Changes automatically according to the connected device
Number of IO-Link ports
4
Digital input
Pin No.
2
4
4
Input type
PNP
Protection Short-circuit protection
Rated input current
Approx.
2.5 mA
Approx. 5.8 mA
ON voltage
13 V or more
OFF voltage
8 V or less
Digital output
Pin No.
4
Output type
PNP
Max. load current (C/Q line)
0.25 A / Output
(Supplied from power supply for sensor / logic US1)
Protection
Short-circuit protection
