SMC Networks EX245-EA2 Series User Manual

- 47 -
No.EX※※-OMW0011-B
7.2. Specifications
Table. 7-1 EX245-DX1 specifications
Item
Description
General
Dimensions (W x L x H) in mm 54 x 120 x 61
Weight
265 g
Housing material
Nylon, PBT
Electrical
Rated supply voltage
24 VDC
Voltage drop to US1(sensor/input)
Max. 1.6 V
Internal current consumption at 24V DC
50 mA or less
Input connection type 8 x M12, 5 pins socket with double allocation
Over Voltage protection
Yes, more than 28 VDC at US1(sensor/input)
Over current protection
Yes
Sensor supply current per connector Max. 0.5 A
Sensor supply current per module
Max. 2 A
Status indication
Yes, per input
Over current indication Yes, per connector
Digital input
Number of inputs
16
Input type
PNP
Signal 1
11 to 30 V
Signal 0
-3 to 5 V
Permissible residual current
Max. 1.5 mA
Input current signal Typ. 4.5 mA
