- 13 -
No.EX※※-OMW0011-B
2. General Specifications
Table. 2-1 EX245 series general specifications
Rated voltage 24 VDC
Allowable instantaneous
electrical stop
1 msec maximum
Protection class
IP65 rating (when fully installed or fitted with protective cover)
(complies with IEC 60529)
Applicable standard
CE / UKCA Marked
UL(CSA)
RoHS directive EN50581: 2012
500 VAC 1 min. (between FE and all accessible terminals)
Insulation resistance
10 M ohm or more
(500 VDC is given between FE and all accessible terminals)
Ambient temperature
Operation: -10 °C to 50 °C
Storage: -20 °C to 60 °C
35% to 85% RH (non-condensing)
Vibration resistance
10 Hz to 57 Hz (constant amplitude) 0.75 mm
57 Hz to 150 Hz (constant acceleration) 49 m/s
2
2 hours for each direction X, Y and Z
(complies with IEC60068-2-6)
Impact resistance
147 m/s
2
is given 3 times for each direction X, Y and Z
(complies with IEC60068-2-27)
Operating environment No corrosive gas
