4.2. Parameterisation
4.2.1. Module parameters
・ Module parameters for valves
The "16 Valves" has the following module parameters.
Table. 4-4 Module parameters of the "16 Valves"
Name
Range of values
Default
Meaning
Valve Output 0
Force to OFF
Force to ON
Hold last state
Force to OFF
When a bus fault occurs, the output
can be made to react in one of the
following ways:
•Force to OFF
•Force to ON
•Hold last state
Valve Output 1
Force to OFF
Force to ON
Hold last state
Force to OFF
… … …
Valve Output 15
Force to OFF
Force to ON
Hold last state
Force to OFF
The "32 Valves" has the following module parameters.
Table. 4-5 Module parameters of the "32 Valves"
Name
Range of values
Default
Meaning
Valve Output 0
Force to OFF
Force to ON
Hold last state
Force to OFF
When a bus fault occurs, the output
can be made to react in one of the
following ways:
•Force to OFF
•Force to ON
•Hold last state
Valve Output 1
Force to OFF
Force to ON
Hold last state
Force to OFF
…
…
…
Valve Output 31
Force to OFF
Force to ON
Hold last state
Force to OFF
