9.8. Parameterisation
The EX245-LA1 / LB1 has the following module parameters.
Table. 9-8 Parameters of Standard IO sub-module
Power supply
and I/O value
at pause
(PROFIenergy)
The EX245-LA1 / LB1
starts the energy saving
mode when the SI Unit
receives the
PROFIenergy
command.
Refer to Table 4-11
-Shutdown, Clear
value
(Default)
-Shutdown, Hold last
state
Table. 9-9 Parameters of Digital output sub-module
Output
operation at
network fault
Set the digital output
signal when PROFINET
communication is in
error
Force to OFF
(Default)
Turn OFF the digital output.
Turn ON the digital output.
Hold last state
Maintain the digital output that the
IO-Link module finally receives.
Table. 9-10 Parameters of IO-Link Device sub-module
IO-Link device
operation at
network fault
∗
1
Set the output process
data values and status
to be sent to the IO-Link
device when PROFINET
communication is in
error.
Clear / PD Out valid
•All outputs are turned OFF
•The process data status is valid.
Hold
•All outputs hold the values of the
last received process data.
•The process data status is valid.
Clear / PD Out invalid
(Default)
•All outputs are turned OFF
•The process data status is
invalid. (Outputs operation of an
IO-Link device depends on the
parameter set for itself.)
Byte Swap
∗
2
the process data, which
is sent and received
between Fieldbus
communication and
IO-Link communication.
For details refer to I/O
byte swap function
Direct (No swap)
(Default)
Data order is not swapped.
Swap 16 bit Swap in the word unit.
Swap 32 bit Swap in the double word unit.
Swap All Swap all bytes
∗1: This parameter is available when using "IO-Link device I/O: ∗/∗" sub-module that include a output
value.
∗2: The available byte swap parameters vary depending on the process data of the device to be
connected. Refer to I/O byte swap function
for details.
