8.2. Specifications
Table. 8-1 EX245-DY1 specifications
Item
Description
General
Dimensions (W x L x H) in mm 54 x 120 x 61
Weight
255 g
Housing material
Nylon, PBT
Electrical
Rated supply voltage
24 VDC
Voltage drop to load supply
Max. 1.6 V
Internal current consumption at 24 V DC
50 mA or less
Load connection 4 x M12, 5 pins socket with double allocation
Over Voltage protection
Yes, more than 28 VDC at US2(solenoid/output)
Over current protection
Yes
Output current per output Max.0.5 A
Output current per module
Max.2 A
Status indication
Yes, per output
Over current indication Yes, per output
Digital output
Number of outputs
8
Output type
PNP
