- 22 -
No.EX※※-OMW0011-B
4. Commissioning
4.1. Configuration
The SI Unit is a modular station that consists of several modules. Setup your PROFINET IO
Controller’s software to reflect the configuration of your system.
4.1.1. GSD file and symbol files
In order to configure the SI Unit with your PROFINET IO Controller’s software the appropriate GSD
file is required. The GSD file contains all of necessary information to configure the SI Unit on your
PROFINET IO Controllers software.
In order to represent the SI Unit in your PROFINET IO Controllers software the appropriate symbol
files are required.
Current GSD file and symbol files name are as follows.
GSD file : GSDML-V2.3-SMC-EX245-SPN-∗∗∗∗∗∗∗∗.xml
Symbol files : GSDML-0083-0011-EX245.bmp
4.1.2. Head modules
The GSD file contains the description for two Head modules and three SI Units.
Table. 4-1 Head modules
Head module
Available SI Unit
EX245-SPN FX EX245-SPN1A
EX245-SPN Cu
EX245-SPN2A
EX245-SPN3A
