- 3 -
No.EX※※-OMW0011-B
9.3. Wiring 58
9.4. Connector allocation and process data 59
9.5. Slot structure 59
9.6. Sub-modules 60
9.7. Diagnostics data on I/O mapping (PQI) 61
9.8. Parameterisation 62
9.9. Diagnosis 66
9.10. LED indicators 67
9.11. Block diagram 68
10. End Plate - EX245-EA2-1/2/3/4/5 70
10.1. Parts and description 70
10.2. Specifications 73
11. Accessories 74
11.1. Markers 74
11.2. Y Connector 75
11.3. Seal cap 77
11.4. Joint pack 79
12. Dimensions 80
12.1. The Modules Manifold 80
13. Troubleshooting 81
13.1. EX245-SPN1A/SPN2A/SPN3A 81
13.2. EX245-DX1 83
13.3. EX245-DY1 83
13.4. EX245-LA1/LB1 84
