Chapter 5 Display and setting of various functions
HRS Series 4.6 Adjustment of Circulating Fluid
5-1
Chapter 5 Display and setting of
various functions
The product can have the displays and settings shown in table 5-1.
Table 5-1 List of function
NO Function Outline
Reference
page
1 Main display
Displays the current temperature of the circulating fluid, discharge pressure of
the circulating fluidhange the circulating fluid temperature.
5.2
2
Alarm display
menu
Indicates alarm number when an alarm occurs.
5.3
3
Inspection
monitor menu
Product temperature, pressure and accumulated operating time can be
checked as daily inspection. Use these for daily inspection.
5.4
4 Key-lock
Keys can be locked so that set values cannot be changed by operator error.
5.5
5
Timer for
operation start
/stop
Timer is used to set the operation start/stop.
5.6
6
Signal for the
completion of
preparation
A signal is output when the circulating fluid temperature reaches the set
temperature, when using contact input/output and serial communication.
5.7
7 Offset function
Use this function when there is a temperature offset between the discharge
temperature of the thermo-chiller and the customer’s device.
5.8
8
Reset after
power failure
Start operation automatically after the power supply is turned on.
5.9
9
Anti-freezing
function
Circulating fluid is protected from freezing during winter time or night time.
Set beforehand if there is a risk of freezing.
5.10
10
Key click sound
setting
Operation panel key sound can be set on/off.
5.11
11
Changing temp.
unit
Temperature unit can be changed.
Centigrade(
o
C) ⇔ Fahrenheit(
o
F)
5.12
12
Changing
pressure unit
Pressure unit can be changed.
MPa
⇔ PSI
5.13
13
Setting of alarm
buzzer
Alarm sound can be set to on/off.
5.14
14
Alarm
customizing
Operation during alarm condition and threshold values can be changed
depending on the alarm type.
5.15
15 Data reset
Functions can be reset to the default settings (settings when shipped from the
factory).
5.16
16
Accumulation
time reset
Reset function when the pump, the fan, or the compressor is replaced.
Accumulated time is reset.
5.17
17 Communication
This function is used for contact input/output or serial communication.
5.18
18
Option
J
[Automatic
water-fill port ]
This function is available for customer who selected option [Automatic fluid
filling] (Refer to P2-1 Name and Function of Parts)
5.19
19
Option
[Drain pan set]
This function is available for customer who purchased drain pan set (part no.:
HRS-WL001).
5.20
20
Option
[Electric
resistivity
sensor set]
This function is available for customer who purchased the electric resistivity
sensor set (part no.: HRS-Dl001).
5.21
Read and understand this manual carefully before changing the
settings.
