Chapter 5 Display and setting of various functions
HRS Series 5.4 Inspection monitor menu
5-9
5.4 Inspection monitor menu
5.4.1 Inspection monitor menu
As a part of the daily inspection, the temperature, pressure and accumulated
operating time can be checked.
Please use this for confirmation of your daily inspection.
5.4.2 Checking of the Inspection monitor menu
The table below explains the check items of the inspection monitor menu.
Table 5.4-1 List of check items of Inspection monitor menu
Display Item Contents
Circulating fluid outlet temperature
Displays the temperature of the circulating fluid outlet.
This temperature does not take offset into
consideration.
Circulating fluid return
port temperature
Displays the temperature of the circulating fluid return.
Temperature of the inlet of the
compressor
Displays the temperature of the inlet of the compressor.
Circulating fluid outlet pressure
Displays the circulating fluid outlet pressure at the
outlet.
Pressure of higher pressure
refrigerant circuit
Displays the pressure of higher pressure side of the
refrigerant circuit.
Pressure of lower pressure
refrigerant circuit
Displays the pressure of lower pressure side of the
refrigerant circuit.
Electric resistivity
Displays the electric resistivity.
Accumulated operation time of the
pump
Displays the accumulated operation time of the pump.
Accumulated operation time of the
fun motor
Displays the accumulated operation time of the fan
motor. (For air-cooled type)
Accumulated operation time of the
compressor
Displays the accumulated operation time of the
compressor.
Accumulated operation time Displays the accumulated operation time.
