Meter Options
Meter options are provided by soft key selections on the monitor panel; select the METERS button to produce
the following selections:
DAW Locks the channel meters to the DAW layers.
Anl Locks the channel meters to the analogue channels.
VU Toggles the feed to the VU meters between the following, as indicated above the VU meters:
MON: The current Left and Right monitor outputs
DMIX: The stereo downmix output level
MIX A: The Main Mix A bus.
Note that any AFL or SOLO selection will automatically cause the VU meters to meter the console’s solo
bus.
PK Switches the meters to peak reading mode; peak readings are held for 3 seconds.
HLD Select this to hold the peak readings indefinitely.
CLR Press to clear the currently held peak readings.
