Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
114
CN215 1-816-113-21 CONNECTOR 15P
< DIODE >
D200 6-502-961-01 DIODE DA2J10100L
D201 6-502-961-01 DIODE DA2J10100L
D202 8-719-053-18 DIODE 1SR154-400TE-25
D203 6-502-961-01 DIODE DA2J10100L
D204 8-719-053-18 DIODE 1SR154-400TE-25
D205 6-502-961-01 DIODE DA2J10100L
D206 6-502-961-01 DIODE DA2J10100L
D207 8-719-053-18 DIODE 1SR154-400TE-25
D208 6-502-961-01 DIODE DA2J10100L
D209 8-719-053-18 DIODE 1SR154-400TE-25
D216 6-502-961-01 DIODE DA2J10100L
0 D218 8-719-061-07 DIODE D5SBA60-F (See Note)
D220 6-502-961-01 DIODE DA2J10100L
D221 6-500-400-01 DIODE BAV99-215
D222 6-502-961-01 DIODE DA2J10100L
D223 6-502-961-01 DIODE DA2J10100L
D227 6-502-961-01 DIODE DA2J10100L
D228 6-502-961-01 DIODE DA2J10100L
D231 8-719-053-18 DIODE 1SR154-400TE-25
D232 8-719-053-18 DIODE 1SR154-400TE-25
< LUG TERMINAL >
* ET200 1-780-408-11 TERMINAL, LUG
< FUSE >
0 F200 1-523-085-11 FUSE (2.5 A/250 V)
0 F201 1-523-085-11 FUSE (2.5 A/250 V)
0 F202 1-523-080-11 FUSE (6.3 A/250 V)
0 F203 1-523-080-11 FUSE (6.3 A/250 V)
< IC >
IC203 6-712-294-01 IC KIA7807API-U/PF
IC204 6-712-295-01 IC KIA7907PI
IC206 6-720-687-01 IC NJW1194
0 IC350 8-759-331-41 IC LM3876TF (See Note)
0 IC351 8-759-331-41 IC LM3876TF (See Note)
< TRANSISTOR >
Q200 6-553-266-01 TRANSISTOR 2PD601ART
Q201 6-553-266-01 TRANSISTOR 2PD601ART
* Q202 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3S
* Q203 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3S
Q204 6-553-266-01 TRANSISTOR 2PD601ART
* Q205 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3S
* Q206 6-551-623-01 TRANSISTOR 2SA2154MFV (TL3S
Q207 6-553-266-01 TRANSISTOR 2PD601ART
Q208 6-553-266-01 TRANSISTOR 2PD601ART
Q209 8-729-023-22 TRANSISTOR 2SD2114K
Q210 8-729-023-22 TRANSISTOR 2SD2114K
Q213 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q214 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q216 6-553-266-01 TRANSISTOR 2PD601ART
Q217 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q218 6-552-891-01 TRANSISTOR LSAR523UBFS8TL
Q219 6-553-266-01 TRANSISTOR 2PD601ART
< RESISTOR >
R200 1-216-833-11 METAL CHIP 10K 5% 1/10W
R201 1-216-845-11 METAL CHIP 100K 5% 1/10W
R202 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R203 1-249-405-91 CARBON 100 5% 1/4W F
R204 1-216-841-11 METAL CHIP 47K 5% 1/10W
R205 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R206 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R207 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R208 1-257-502-11 CARBON 820 5% 1/2W
R209 1-257-502-11 CARBON 820 5% 1/2W
R210 1-216-864-11 SHORT CHIP 0
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R214 1-216-833-11 METAL CHIP 10K 5% 1/10W
R215 1-216-864-11 SHORT CHIP 0
R220 1-257-502-11 CARBON 820 5% 1/2W
R221 1-257-502-11 CARBON 820 5% 1/2W
0 R222 1-249-399-91 CARBON 33 5% 1/4W F
R223 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R224 1-216-841-11 METAL CHIP 47K 5% 1/10W
R225 1-216-837-11 METAL CHIP 22K 5% 1/10W
R226 1-216-837-11 METAL CHIP 22K 5% 1/10W
R227 1-216-841-11 METAL CHIP 47K 5% 1/10W
R228 1-216-845-11 METAL CHIP 100K 5% 1/10W
R229 1-216-845-11 METAL CHIP 100K 5% 1/10W
R230 1-216-845-11 METAL CHIP 100K 5% 1/10W
R231 1-216-845-11 METAL CHIP 100K 5% 1/10W
0 R232 1-249-405-91 CARBON 100 5% 1/4W F
R233 1-216-845-11 METAL CHIP 100K 5% 1/10W
R234 1-216-841-11 METAL CHIP 47K 5% 1/10W
R235 1-216-845-11 METAL CHIP 100K 5% 1/10W
R236 1-216-845-11 METAL CHIP 100K 5% 1/10W
R237 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R238 1-249-405-91 CARBON 100 5% 1/4W F
R239 1-216-841-11 METAL CHIP 47K 5% 1/10W
R240 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R241 1-216-845-11 METAL CHIP 100K 5% 1/10W
R242 1-216-809-11 METAL CHIP 100 5% 1/10W
R243 1-257-451-11 CARBON 100K 5% 1/2W
R244 1-257-451-11 CARBON 100K 5% 1/2W
R247 1-257-372-11 CARBON 2.2K 5% 1/2W
R248 1-257-372-11 CARBON 2.2K 5% 1/2W
R251 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R252 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R256 1-216-845-11 METAL CHIP 100K 5% 1/10W
R260 1-216-833-11 METAL CHIP 10K 5% 1/10W
R261 1-216-833-11 METAL CHIP 10K 5% 1/10W
R262 1-216-845-11 METAL CHIP 100K 5% 1/10W
R264 1-216-841-11 METAL CHIP 47K 5% 1/10W
R267 1-216-833-11 METAL CHIP 10K 5% 1/10W
R271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R281 1-257-434-11 CARBON 4.7K 5% 1/2W
R282 1-257-434-11 CARBON 4.7K 5% 1/2W
R283 1-216-841-11 METAL CHIP 47K 5% 1/10W
R284 1-216-809-11 METAL CHIP 100 5% 1/10W
R285 1-216-809-11 METAL CHIP 100 5% 1/10W
R286 1-216-809-11 METAL CHIP 100 5% 1/10W
R287 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R288 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R289 1-216-809-11 METAL CHIP 100 5% 1/10W
AMP
Note: When the D218, IC350 and IC351 on the AMP board is replaced, refer to “NOTE OF REPLACING THE
D218, IC350 AND IC351 ON THE AMP BOARD AND THE COMPLETE AMP BOARD” on page 4.
