Sony HAP-S1 Service Manual

HAP-S1
7
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. SIDE PANEL (L/R) ASSY
(Page 9)
2-3. FRONT PANEL (ALG) BLOCK, FUSE (F902)
(Page 10)
2-4. HP BOARD
(Page 11)
2-5. POWER KEY BOARD
(Page 11)
2-6. LCD HOLDER BLOCK
(Page 12)
2-7. LCD PANEL (LCD1)
(Page 12)
2-13. ALLEGRO-ANT-R BOARD
(Page 16)
2-8. WLAN/BT COMBO CARD (WBC1)
(Page 13)
2-9. CLAMP FILTER (FERRITE CORE) (FC1, FC2)
(Page 14)
2-14. CLAMP FILTER (FERRITE CORE) (FC4)
(Page 17)
2-15. DCDC BOARD-1
(Page 18)
2-16. DCDC BOARD-2
(Page 19)
2-17. WIRE HOLDER
(Page 20)
2-10. FERRITE CORE (FC3)
(Page 14)
2-11. HDD (HDD1)
(Page 15)
2-12. ANT HOLDER BLOCK (RIGHT SIDE)
(Page 15)
To next page.
