Sony HAP-S1 Service Manual

HAP-S1
31
SECTION 3
TEST MODE
1. Entering Method of The Service Diag Mode
Procedure:
1. Connect the power cord to an outlet.
2. After becoming the standby state, while holding down two
keys of the [HOME] and [BACK], press two keys in order of
the [u] → [
?/1
].
3. Enter the service DIAG mode, “Main Menu” is displayed on
the liquid crystal display.
Main Menu
1. Version Info
2. ID Info
3. LED/KEY
4. LCD/Others
5. HDD
6. Audio
Main Menu
5. HDD
6. Audio
7. WiFi
8. Ether
9. IR Learning
10. Quit
2. Operation Method of The Service DIAG Mode
It can operate the service DIAG mode with the key of the main unit
or remote commander (RM-ANU183). A key having no particular
description in the text, indicates the main unit key
Key Assign
Operation Main unit key
Remote com-
mander (RM-
ANU183) key
Moves to the cursor
and selects the item
PUSH ENTER
(UP/DOWN)
./>
Enters the item PUSH ENTER
u
Returns to the main
menu
HOME –
Returns to the previ-
ous menu
BACK –
3. Releasing Method of The Service DIAG Mode
• Press the [
?/1
] button (Except the state of “3-3.KEY Check”,
“5-5.SMART Short Test” and “5-6.SMART Long Test”).
• Select the “10. QUIT” on the main menu.
4. Operation of The Service DIAG Mode
4-1. Version Info
It can display the version information.
Procedure:
1. Enter the service DIAG mode.
(Refer to “1. Entering Method of The Service DIAG Mode”)
2. Rotate the [PUSH ENTER] knob to select the “1. Version Info”.
3. Press the [PUSH ENTER] knob to enter the “1. Version Info”
mode.
1.Version Info
1. uCON ver. 040
0007440R
CEL
HAP-S1
0
2. MPU ver.
3. Region
4. Model
5. HW Rev.
6. Back to Main Menu
(Displayed characters/values in the above fi gure are example)
4-2. ID Info
It can display the ID information.
Procedure:
1. Enter the service DIAG mode.
(Refer to “1. Entering Method of The Service DIAG Mode”)
2. Rotate the [PUSH ENTER] knob to select the “2. ID Info”.
3. Press the [PUSH ENTER] knob to enter the “2. ID Info” mode.
2.ID Info
1. Service TAG B00001EE8AA9
02012
D8:D4:3C:0A:6F:5E
BC:85:56:F8:F6:45
2. TV-ID ver.
3. MAC Addr(Ether)
4. MAC Addr(WiFi)
5. Back to Main Menu
(Displayed characters/values in the above fi gure are example)

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \
