2-15. DCDC BOARD-1
1 Remove wires from
three lead pins.
2 connector
(CN4005)
4 connector
(CN4008)
5 connector
(CN4009)
3 connector
(CN4013)
:LUHVHWWLQJ
DIGITAL IO board
lead pin
lead pin
lead pin
:LUHVHWWLQJ
DIGITAL IO board
DCDC board
wire holder
