Sony HAP-S1 Service Manual

HAP-S1
38
SECTION 4
ELECTRICAL CHECK
HDD CHECK
It can check the result of hard disk drive test.
1. Operation of The SMART Long Test
The SMART long test is mode to perform the overall test of hard
disk drive.
When checking the hard disk drive, perform the SMART long test.
Procedure:
1. Enter the service DIAG mode.
(Refer to “1. Entering method of the service DIAG mode” on
page 31)
2. Rotate the [PUSH ENTER] knob to select the “5. HDD”.
3. Press the [PUSH ENTER] knob to enter the “5. HDD” mode.
5.HDD
1. Model TOSHIBA MQ01ABF050
53TSC1MGT
AM001Y
2. Serial
3. Firmware Rev.
4. SMART Data Read(Need USB Memory)
5. SMART Short Test (2min)
6. SMART Long Test (2-4 hours)
5.HDD
2. Serial 53TSC1MGT
AM001Y3. Firmware Rev.
4. SMART Data Read(Need USB Memory)
5. SMART Short Test (2min)
6. SMART Long Test (2-4 hours)
7. Back to Main Menu
(Displayed characters/values in the above fi gure are example)
4. Rotate the [PUSH ENTER] knob to select the “6. SMART
Long Test (2-4 hours)”.
5. Press the [PUSH ENTER] knob to enter the “6. SMART Long
Test (2-4 hours)” mode.
Note 1: Two keys of the [HOME] and [BACK] is invalid during SMART
long test.
5-6.SMART Long Test
SMART Long Test is running...
This test needs about 2-4 hours.
50% of test remaing.
Abort
(Displayed characters/values in the above fi gure are example)
6. Press the [PUSH ENTER] knob to abort the SMART long test.
7. When the result of test is OK, following screen is displayed on
the liquid crystal display.
5-6.SMART Long Test
SMART Test is Succeded.
Back to HDD Menu
Note 2: When “SMART Test is Failed.” is displayed on the liquid crystal
display, refer to “3. Checking Method of The SMART Test Re-
sult” on page 39.
2. Operation of The SMART Short Test
The SMART short test is mode to perform the simple test of hard
disk drive in a short time.
Procedure:
1. Enter the “5. HDD” mode.
(Refer to “1. Operation of The SMART Long Test”)
2. Rotate the [PUSH ENTER] knob to select the “5. SMART
Short Test (2min)”.
3. Press the [PUSH ENTER] knob to enter the “5. SMART Short
Test (2min)” mode.
Note 1: Two keys of the [HOME] and [BACK] is invalid during SMART
short test.
5-5.SMART Short Test
SMART Short Test is running...
This test needs about 2 minutes.
50% of test remaing.
Abort
(Displayed characters/values in the above fi gure are example)
4. Press the [PUSH ENTER] knob to abort the SMART short test.
5. When the result of test is OK, following screen is displayed on
the liquid crystal display.
5-5.SMART Short Test
SMART Test is Succeded.
Back to HDD Menu
Note 2: When “SMART Test is Failed.” is displayed on the liquid crystal
display, refer to “3. Checking Method of The SMART Test Re-
sult” on page 39.
