Sony HAP-S1 Service Manual

HAP-S1
37
4-8. Ether
Procedure:
1. Connect the main unit to the router with the network LAN
cable.
2. Enter the service DIAG mode.
(Refer to “1. Entering Method of The Service DIAG Mode” on
page 31)
3. Rotate the [PUSH ENTER] knob to select the “8. Ether”.
4. Press the [PUSH ENTER] knob to enter the “8. Ether” mode.
8.Ether
1. Network Info
2. Ping
3. Back to Main Menu
4-8-1. Network Info
It can display the wired network information.
Procedure:
1. Enter the “8. Ether” mode.
(Refer to “4-8. Ether”)
2. Rotate the [PUSH ENTER] knob to select the “1. Network
Info”.
3. Press the [PUSH ENTER] knob to enter the “1. Network Info”
mode.
Note: “1. IP Address”, “2. Subnet Mask” and “3. Default Gateway” sup-
ports only DHCP.
8-1.Network Info
1. IP Address
2. Subnet Mask
3. Default Gateway
4. Linkup Speed
5. Back to Main Menu
172.17.100.27
255.255.0.0
172.17.0.200
1Gbps
(Displayed characters/values in the above fi gure are example)
4-8-2. Ping
It can display the results indicating whether or not the gateway
responded to the PING.
Note: This mode supports only DHCP.
Procedure:
1. Enter the “8. Ether” mode.
(Refer to “4-8. Ether”)
2. Rotate the [PUSH ENTER] knob to select the “2. Ping”.
3. Press the [PUSH ENTER] knob to enter the “2. Ping” mode.
4. The results indicating whether or not the gateway responded to
the PING is displayed on the liquid crystal display.
(When the gateway does not respond to the PING, “Error!!
Can’t get gateway-ip” is displayed on the liquid crystal dis-
play)
8-2.Ping
ping to 172.17.0.200 : OK
Back to Ether Menu
(Displayed characters/values in the above fi gure are example)
4-9. IR Learning
This item cannot use in this unit.
4-10. Quit
Rotate the [PUSH ENTER] knob to select the “10. Quit” and press
the [PUSH ENTER] knob, service DIAG mode is released.

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
