Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
116
< LUG TERMINAL >
* EE400 1-780-408-11 TERMINAL, LUG
* EE401 1-780-408-11 TERMINAL, LUG
* EE402 1-780-408-11 TERMINAL, LUG
* EE403 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB400 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB401 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB402 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB404 1-469-139-21 FERRITE, EMI (SMD) (2012)
< IC >
IC400 8-759-832-29 IC NJM4580M- (TE2)
IC401 8-759-832-29 IC NJM4580M- (TE2)
IC402 8-759-832-29 IC NJM4580M- (TE2)
IC403 6-716-834-01 IC MM1836A50NRE
IC404 6-708-637-01 IC NJM2871BF33-TE2
IC405 6-720-672-01 IC PCM1795DBR
IC406 6-706-487-01 IC TC7SH08FU
IC407 8-759-680-48 IC TC7WH157FK
IC408 8-759-096-87 IC TC7WU04FU (TE12R)
IC409 8-759-096-87 IC TC7WU04FU (TE12R)
IC410 8-759-680-48 IC TC7WH157FK
IC411 6-700-067-01 IC HD74LV161ATELL
IC412 6-600-060-01 IC TC7WZ32FK
IC413 6-708-637-01 IC NJM2871BF33-TE2
IC414 6-708-637-01 IC NJM2871BF33-TE2
IC415 8-759-832-29 IC NJM4580M- (TE2)
< JACK >
J401 1-794-984-11 JACK, PIN 6P
(D/A DIRECT LINE OUT, LINE IN 1, LINE IN 2)
< TRANSISTOR >
Q400 8-729-023-22 TRANSISTOR 2SD2114K
Q401 8-729-023-22 TRANSISTOR 2SD2114K
< RESISTOR >
R400 1-257-470-11 CARBON 220K 5% 1/2W
R401 1-257-470-11 CARBON 220K 5% 1/2W
R402 1-257-371-11 CARBON 1K 5% 1/2W
R403 1-257-371-11 CARBON 1K 5% 1/2W
R404 1-257-371-11 CARBON 1K 5% 1/2W
R405 1-257-371-11 CARBON 1K 5% 1/2W
R406 1-257-428-11 CARBON 560 5% 1/2W
R407 1-257-429-11 CARBON 680 5% 1/2W
R408 1-257-428-11 CARBON 560 5% 1/2W
R409 1-257-429-11 CARBON 680 5% 1/2W
R410 1-257-428-11 CARBON 560 5% 1/2W
R411 1-257-428-11 CARBON 560 5% 1/2W
R412 1-257-429-11 CARBON 680 5% 1/2W
R413 1-257-429-11 CARBON 680 5% 1/2W
R414 1-257-428-11 CARBON 560 5% 1/2W
R415 1-257-428-11 CARBON 560 5% 1/2W
R416 1-257-428-11 CARBON 560 5% 1/2W
R417 1-257-428-11 CARBON 560 5% 1/2W
R418 1-257-429-11 CARBON 680 5% 1/2W
R419 1-257-429-11 CARBON 680 5% 1/2W
R420 1-257-429-11 CARBON 680 5% 1/2W
R421 1-257-429-11 CARBON 680 5% 1/2W
R422 1-257-441-11 CARBON 10K 5% 1/2W
R423 1-216-801-11 METAL CHIP 22 5% 1/10W
R424 1-216-801-11 METAL CHIP 22 5% 1/10W
R425 1-216-801-11 METAL CHIP 22 5% 1/10W
R426 1-216-801-11 METAL CHIP 22 5% 1/10W
R427 1-216-801-11 METAL CHIP 22 5% 1/10W
R428 1-216-801-11 METAL CHIP 22 5% 1/10W
R429 1-216-809-11 METAL CHIP 100 5% 1/10W
R430 1-216-801-11 METAL CHIP 22 5% 1/10W
R431 1-216-809-11 METAL CHIP 100 5% 1/10W
R432 1-216-809-11 METAL CHIP 100 5% 1/10W
R433 1-216-809-11 METAL CHIP 100 5% 1/10W
R434 1-216-809-11 METAL CHIP 100 5% 1/10W
R435 1-216-809-11 METAL CHIP 100 5% 1/10W
R436 1-216-809-11 METAL CHIP 100 5% 1/10W
R437 1-216-797-11 METAL CHIP 10 5% 1/10W
R438 1-216-809-11 METAL CHIP 100 5% 1/10W
R439 1-216-797-11 METAL CHIP 10 5% 1/10W
R440 1-218-845-11 METAL CHIP 820 0.5% 1/10W
R441 1-216-857-11 METAL CHIP 1M 5% 1/10W
R442 1-216-809-11 METAL CHIP 100 5% 1/10W
R443 1-216-809-11 METAL CHIP 100 5% 1/10W
R444 1-216-809-11 METAL CHIP 100 5% 1/10W
R445 1-216-833-11 METAL CHIP 10K 5% 1/10W
R446 1-216-809-11 METAL CHIP 100 5% 1/10W
R447 1-216-817-11 METAL CHIP 470 5% 1/10W
R448 1-216-857-11 METAL CHIP 1M 5% 1/10W
R449 1-216-797-11 METAL CHIP 10 5% 1/10W
R450 1-218-845-11 METAL CHIP 820 0.5% 1/10W
R452 1-216-809-11 METAL CHIP 100 5% 1/10W
R455 1-216-833-11 METAL CHIP 10K 5% 1/10W
R458 1-216-833-11 METAL CHIP 10K 5% 1/10W
R461 1-216-864-11 SHORT CHIP 0
R462 1-216-845-11 METAL CHIP 100K 5% 1/10W
R463 1-216-845-11 METAL CHIP 100K 5% 1/10W
R464 1-216-809-11 METAL CHIP 100 5% 1/10W
R465 1-257-372-11 CARBON 2.2K 5% 1/2W
R466 1-257-372-11 CARBON 2.2K 5% 1/2W
R467 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R468 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R469 1-216-845-11 METAL CHIP 100K 5% 1/10W
R470 1-216-845-11 METAL CHIP 100K 5% 1/10W
R471 1-216-864-11 SHORT CHIP 0
R472 1-216-864-11 SHORT CHIP 0
R473 1-216-864-11 SHORT CHIP 0
R478 1-216-864-11 SHORT CHIP 0
R479 1-216-864-11 SHORT CHIP 0
R484 1-216-864-11 SHORT CHIP 0
R485 1-216-864-11 SHORT CHIP 0
R486 1-216-813-11 METAL CHIP 220 5% 1/10W
R489 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X400 1-795-779-21 VIBRATOR, CRYSTAL (22.5792 MHz)
X401 1-814-344-11 QUARTZ CRYSTAL UNIT (24.576 MHz)
*************************************************************
DAC
