Sony HAP-S1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HAP-S1
119
R4054 1-218-933-11 METAL CHIP 22 5% 1/16W
R4055 1-218-933-11 METAL CHIP 22 5% 1/16W
R4056 1-218-941-81 METAL CHIP 100 5% 1/16W
R4057 1-218-933-11 METAL CHIP 22 5% 1/16W
R4058 1-218-933-11 METAL CHIP 22 5% 1/16W
R4059 1-218-933-11 METAL CHIP 22 5% 1/16W
R4060 1-218-933-11 METAL CHIP 22 5% 1/16W
R4061 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4062 1-216-864-11 SHORT CHIP 0
R4063 1-218-933-11 METAL CHIP 22 5% 1/16W
R4064 1-218-933-11 METAL CHIP 22 5% 1/16W
R4065 1-218-933-11 METAL CHIP 22 5% 1/16W
R4066 1-218-933-11 METAL CHIP 22 5% 1/16W
R4067 1-218-933-11 METAL CHIP 22 5% 1/16W
R4068 1-218-945-11 METAL CHIP 220 5% 1/16W
R4075 1-216-295-91 SHORT CHIP 0
R4079 1-218-941-81 METAL CHIP 100 5% 1/16W
R4082 1-216-864-11 SHORT CHIP 0
R4083 1-216-864-11 SHORT CHIP 0
R4084 1-218-945-11 METAL CHIP 220 5% 1/16W
R4091 1-218-990-81 SHORT CHIP 0
R4092 1-218-990-81 SHORT CHIP 0
R4093 1-218-990-81 SHORT CHIP 0
R4094 1-218-990-81 SHORT CHIP 0
R4095 1-218-990-81 SHORT CHIP 0
R4096 1-218-990-81 SHORT CHIP 0
R4097 1-218-990-81 SHORT CHIP 0
R4098 1-218-990-81 SHORT CHIP 0
R4099 1-218-990-81 SHORT CHIP 0
R4100 1-218-990-81 SHORT CHIP 0
R4101 1-218-990-81 SHORT CHIP 0
R4111 1-218-990-81 SHORT CHIP 0
R4113 1-216-864-11 SHORT CHIP 0
R4114 1-216-864-11 SHORT CHIP 0
R4115 1-216-864-11 SHORT CHIP 0
R4116 1-218-990-81 SHORT CHIP 0
R4117 1-218-990-81 SHORT CHIP 0
R4118 1-218-990-81 SHORT CHIP 0
R4119 1-216-864-11 SHORT CHIP 0
R4120 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X4001 1-814-344-11 QUARTZ CRYSTAL UNIT (24.576 MHz)
*************************************************************
A-1945-063-A FPGA DSP BOARD, COMPLETE
************************
< CAPACITOR >
C101 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C104 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C109 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C111 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C113 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C115 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C116 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
* C119 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C120 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C201 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C203 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C204 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C207 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C209 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C210 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C211 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C212 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C213 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C215 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C216 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C217 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C218 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C219 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C220 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C221 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C222 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C223 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C224 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C225 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C226 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C227 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C228 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C229 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C230 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C231 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C232 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C233 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C234 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C235 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C236 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C237 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C238 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C239 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C240 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C241 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C242 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C243 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C244 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
C245 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C246 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C247 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C248 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C249 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C250 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C251 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C252 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C253 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C254 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C255 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C256 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C257 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C258 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C259 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
DIGITAL IO FPGA DSP

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
