Sony HAP-S1 Service Manual

HAP-S1
HAP-S1
7373
• Waveforms
– MAIN Board – – DIGITAL IO Board – – FPGA DSP Board – – DAC Board – – U-COM Board –
– DCDC Board –
3
IC701 4 (SW)
10 V/DIV, 500 ns/DIV
980 ns
35.2 Vp-p
qa
IC4004 qd (MCKOUT)
2 V/DIV, 20 ns/DIV
40.2 ns
4.1 Vp-p
qs
IC4004 qf (BCKOUT)
2 V/DIV, 100 ns/DIV
324 ns
4.1 Vp-p
qd
IC4004 qg (LRCKOUT)
2 V/DIV, 10 Ps/DIV
20.8 Ps
4 Vp-p
qf
IC4004 e; (XMCK)
2 V/DIV, 20 ns/DIV
40.6 ns
3.9 Vp-p
qh
IC4006 5 (Y)
2 V/DIV, 20 ns/DIV
34.6 ns
4.2 Vp-p
4.4 Ps
2.7 Vp-p
qj
IC4007 7 (Y1)
2 V/DIV, 2 Ps/DIV
69.2 Ps
3.7 Vp-p
qk
IC4007 9 (Y2)
2 V/DIV, 20 Ps/DIV
ql
IC4008 3 (CLK_OUT)
2 V/DIV, 20 ns/DIV
40.6 ns
4.3 Vp-p
qg
IC4004 ea (XOUT)
2 V/DIV, 20 ns/DIV
40.6 ns
3.9 Vp-p
1
IC202 1 (BST)
2 V/DIV, 1 Ps/DIV
2.6 Ps
6.6 Vp-p
2
IC602 4 (XTLO)
500 mV/DIV, 10 ns/DIV
40 ns
0.8 Vp-p
ea
IC407 5 (Y)
2 V/DIV, 20 ns/DIV
40.2 ns
4.1 Vp-p
eg
IC409 7
2 V/DIV, 20 ns/DIV
40.2 ns
5 Vp-p
es
IC410 5 (Y)
2 V/DIV, 20 ns/DIV
40.2 ns
4.1 Vp-p
ed
IC412 6, 7
2 V/DIV, 20 ns/DIV
40.2 ns
4.3 Vp-p
ef
IC409 1, 2
2 V/DIV, 20 ns/DIV
40.2 ns
4.7 Vp-p
wa
IC701 5, 6
2 V/DIV, 100 ns/DIV
165 ns
3.7 Vp-p
ws
IC702 1 (CLOCK)
2 V/DIV, 100 ns/DIV
165 ns
4.4 Vp-p
5.6 Ps
3.7 Vp-p
wd
IC702 w; (DAO_LRCLK)
2 V/DIV, 2 Ps/DIV
22.8 Ps
3.8 Vp-p
wg
IC702 wd (DAI_LRCLK)
2 V/DIV, 10 Ps/DIV
wf
IC702 wa (DAO_SCLK)
2 V/DIV, 50 ns/DIV
88 ns
3.7 Vp-p
wh
IC702 wf (DAI_SCLK)
2 V/DIV, 200 ns/DIV
356 ns
3.7 Vp-p
ta
IC2402 1 (BOOT)
10 V/DIV, 2 Ps/DIV
3 Ps
17.2 Vp-p
ts
IC2403 1 (BOOT)
10 V/DIV, 2 Ps/DIV
2.9 Ps
18 Vp-p
td
IC2404 1 (BOOT)
10 V/DIV, 5 Ps/DIV
15 Ps
16.8 Vp-p
ra
IC5006 rk (XTALO)
1 V/DIV, 100 ns/DIV
251 ns
2.3Vp-p
