Sony HAP-S1 Service Manual

HAP-S1
84
– AMP Board –
IC206 NJW1194
INA1
1
INA2
2
INA3
3
INA4
4
GND
5
GND
13
TONE_TR1A
14
TONE_BA1A
15
TONE_BA2A
16
GND
7
DCCAP_A
6
OUTA 8
VDDOUT
9
DATA
10
CLOCK
11
LATCH
12
+
–
+
–
INB132
INB2
31
INB3
30
INB4
29
GND
28
DCCAP_B
27
GND
26
OUTB
25
ADR1
24
ADR0
23
V+
22
V–
21
TONE_BA2B
17
TONE_BA1B
18
TONE_TR1B
19
GND
20
CONTROL
LOGIC
TONE TONE
ZERO CROSS
DETECTION
IC350, 351 LM3876TF
321
V+
NC
OUTPUT
V–
NC NC
MUTE
VIN–
VIN+
NC
5 9 114 106 8
GND
7

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
