Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
106
HCD-FL3
FRONT REAR AMP GC
0 R456 1-245-235-21 METAL 0.22 10% 2W F
R457 1-249-417-11 CARBON 1K 5% 1/4W
R458 1-249-431-11 CARBON 15K 5% 1/4W
R460 1-260-076-11 CARBON 10 5% 1/2W
0 R461 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R462 1-212-881-11 FUSIBLE 100 5% 1/4W F
R469 1-249-429-11 CARBON 10K 5% 1/4W
0 R470 1-202-972-61 FUSIBLE 1 5% 1/4W F
R471 1-249-421-11 CARBON 2.2K 5% 1/4W
R472 1-249-433-11 CARBON 22K 5% 1/4W
R473 1-249-439-11 CARBON 68K 5% 1/4W
R474 1-249-426-11 CARBON 5.6K 5% 1/4W
R475 1-249-421-11 CARBON 2.2K 5% 1/4W
R476 1-249-421-11 CARBON 2.2K 5% 1/4W
R477 1-249-435-11 CARBON 33K 5% 1/4W
R478 1-249-431-11 CARBON 15K 5% 1/4W
R481 1-249-417-11 CARBON 1K 5% 1/4W
R482 1-249-437-11 CARBON 47K 5% 1/4W
R483 1-249-415-11 CARBON 680 5% 1/4W
R484 1-249-437-11 CARBON 47K 5% 1/4W
0 R485 1-245-235-21 METAL 0.22 10% 2W F
0 R486 1-245-235-21 METAL 0.22 10% 2W F
R487 1-249-417-11 CARBON 1K 5% 1/4W
R488 1-249-433-11 CARBON 22K 5% 1/4W
R490 1-260-076-11 CARBON 10 5% 1/2W
R491 1-249-441-11 CARBON 100K 5% 1/4W
R492 1-249-441-11 CARBON 100K 5% 1/4W
< THERMISTOR >
TH401 1-807-796-11 THERMISTOR
**************************************************************
A-4728-396-A GC BOARD, COMPLETE
*******************
4-238-986-01 HOLDER (FL)
< CAPACITOR >
C201 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C202 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C203 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C204 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C205 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C206 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C207 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C208 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C209 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C211 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C212 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C243 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C250 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C251 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C260 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C261 1-162-953-11 CERAMIC CHIP 100PF 5% 50V
C262 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C277 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C281 1-126-916-11 ELECT 1000uF 20% 6.3V
C282 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C285 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C286 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C287 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C288 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C289 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C290 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C291 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C292 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C293 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C294 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C295 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C296 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C297 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C298 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C299 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C300 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
< CONNECTOR >
CN201 1-785-337-11 PIN, CONNECTOR (LIGHT ANGLE) 11P
CN202 1-569-912-11 SOCKET, CONNECTOR 19P
CN203 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
CN204 1-569-910-11 SOCKET, CONNECTOR 17P
CN206 1-560-909-11 SOCKET, CONNECTOR 15P
CN207 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
D202 8-719-069-29 DIODE RB520S-30TE61
D203 8-719-083-89 DIODE 11ES2N-TB5
D204 8-719-988-61 DIODE 1SS355TE-17
< GROUND TERMINAL >
* EP201 1-537-738-21 TERMINAL, EARTH
* EP202 1-537-738-21 TERMINAL, EARTH
< SHORT >
FB201 1-216-864-11 SHORT CHIP 0
FB202 1-216-864-11 SHORT CHIP 0
FB284 1-216-864-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
FL201 1-518-811-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 6-801-394-01 IC MB90M407PF-G-118-BND
IC202 8-759-828-32 IC PT8300
< SHORT >
JR201 1-216-864-11 SHORT CHIP 0
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
