17
HCD-FL3
3-20. SP RELAY BOARD
2
screw (BVTP3
×
8)
5
screw claws
1
two screws
(BVTP3
×
8)
4
three connectors
(CN801, 803, 804)
6
SP relay board
front rear AMP board
center SW AMP board
3
chassis
