Sony HCD-FL3 - Base Unit Section (BU-30 BD60)

96
HCD-FL3
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
701 3-531-576-11 RIVET
702 A-4728-678-A BD BOARD COMPLETE
703 4-233-832-01 GEAR (LB)
704 4-233-831-01 GEAR (LA)
705 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
0 706 A-4735-188-A BU-30 (60) ASSY
9-14. BASE UNIT SECTION
(BU30BD60)
not supplied
705
702
701
704
703
706
