Sony HCD-FL3 - Chassis Section-3

90
HCD-FL3
9-8. CHASSIS SECTION-3
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
401 3-970-608-01 SUMITITE (B3), +BV
402 A-4676-869-A CENTER SW AMP BOARD, COMPLETE
(E2, E51, AR, MX)
402 A-4728-428-A CENTER SW AMP BOARD, COMPLETE
(AUS, SP)
403 A-4676-866-A FRONT REAR AMP BOARD, COMPLETE
(E2, E51, AR, MX)
403 A-4728-418-A FRONT REAR AMP BOARD, COMPLETE
(AUS, SP)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
403
#1
#4
not supplied
chassis section-4
401
401
402
#1
#1
#1
#1
#4
#1
not supplied
not
supplied
not supplied
