Sony HCD-FL3 - CD Mechanism Block

12
HCD-FL3
3-10. SW BOARD, HEAD (A) BOARD AND HEAD (B) BOARD
3-11. CD MECHANISM BLOCK
6 screw (PTT 2 × 4)
4 screw (PTT 2 × 4)
3 SW board
2 five claws
5 head (A) board
7 head (B) board
1 Remove the four solders.
5 two connector
(CN805, 806)
6 CD mechanism block
2 connector
(CN903)
1 wire (flat type) (11 core)
(CN105)
3 connector
(CN807)
4 five screws
(BVTP3
× 8
)
