Sony HCD-FL3 - Printed Wiring Board - DSP Board (Conductor Side)

HCD-FL3
4949
8-20. PRINTED WIRING BOARD – DSP Board (Conductor Side) – • See page 35 for Circuit Boards Location.
IC621
IC622
IC631
IC602
FB702
R616
FB703
DSP BOARD
(CONDUCTOR SIDE)
1-684-272-
11
(21)
(CHASSIS)
2
3
1
2
3
1
OPTICAL
DIGITAL
IN
OPTICAL
DIGITAL
OUT
IC621
IC622
J701
R
L
IN
R
L
OUT
MD (VIDEO)
E
E
E
E
(AUS)
(EXCEPT AUS)
(EXCEPT AUS)
(AUS)
(AUS)
(EXCEPT AUS)
(AUS)
(EXCEPT AUS)
1
2
F
MC BOARD
CN104
G
MC BOARD
CN103
(CHASSIS)
L
MIC BOARD
CN318
13
E
E
E
EEE
E
E
M
CENTER SW
AMP BOARD
CN802
N
FRONT REAR
AMP BOARD
CN801
1 2 3 4 5 6 7 8 9 10 11 12 13 14
A
B
C
D
E
F
G
H
I
(Page 54) (Page 56)
(Page 66)
(Page 46)
(Page 46)
D601 D-12
D606 I-6
D611 B-6
D612 B-6
D741 H-6
D742 H-6
IC602 E-11
IC621 D-2
IC622 E-2
IC631 D-13
Q601 B-4
Q602 B-4
Q701 H-5
Q702 H-9
Ref. No. LocationRef. No. Location
• Semiconductor Location
Ref. No. Location
Q703 H-10
Q704 H-11
Q710 H-12
Q711 G-9
Q751 H-4
Q752 H-9
Q753 H-9
Q754 H-10
