8-16. SCHEMATIC DIAGRAM – TC DOOR Section –
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
no mark : TUNER
PM302PM301
CP301 CP303
CP302 CP304
D309 D310
R338
S325
NO809B
NO810
NO809A
CN319
NO813
S326
1SS355 1SS355
2.2k
2P
2P
2P
2P
6P
TC DOOR SW
SOLENOID A
SOLENOID B
D GND
KEYS RTN
A
OPEN/CLOSE DETECT
M/LED GND
TC HOLDER
OPEN
TC HOLDER
OPEN
(DECK B)(DECK A)
CASSETTE LID
(Page 63)
