8-24. PRINTED WIRING BOARD – FRONT REAR AMP Board – • See page 35 for Circuit Boards Location.
D401 B-5
D402 C-5
D420 C-6
D421 C-3
D431 B-6
D432 C-8
D451 B-5
D452 C-5
D471 C-7
D481 B-6
D482 C-8
D490 C-9
D491 B-2
IC401 D-5
IC431 D-8
Q401 B-5
Q419 C-6
Q420 C-6
Q421 B-5
Q422 B-6
Q423 C-4
Q431 B-9
Q451 C-4
Q471 B-8
Q472 B-9
Q473 C-7
Q481 C-7
• Semiconductor
Location
Ref. No. Location
(Page 58)
IC401
IC431
D452
D402
D482
D432
4
1
1
6
O
TRANS
BOARD
CN915
FRONT REAR AMP BOARD
1-684-260-
11
(21)
17
N
DSP BOARD
CN702
E
E
E
E
E
E
E
E
E
E
E
E
P
SP RELAY BOARD
CN801
A
B
C
D
E
1 2 3 4 5 6 7 8 9 10
(Page 70)
(Page 49)
