Sony HCD-FL3 - Page 53

HCD-FL3
5353
Approx.
0.4 Vp-p
Approx.
0.3 Vp-p
es IC601 qf (SCKOUT)
ws IC101 qd (X-OUT)
• Waveforms
– BD Board –
1.1 ± 0.4 Vp-
p
1 IC103 qg (RFAC) (CD Play Mode)
2.5 Vp-p
7.5
µ s
2 IC101 wh (MDP) (CD Play Mode)
3 IC101 el (FE) (CD Play Mode)
4 IC101 ra (TE) (CD Play Mode)
0.65 ± 0.15 Vp-
p
5 IC101 t; (RFDC) (CD Play Mode)
5 Vp-
p
59 ns
2.1 Vp-
p
12.1 µs
qa Q4, Q5 (Base) (REC Mode)
10.8Vp-p
12.1 µs
qs Q4, Q5 (Collector) (REC Mode)
6 IC101 yj (XTAO)
– SP RELAY Board –
0.4 Vp-
p
12.1 µs
qd Q4, Q5 (Emitter) (REC Mode)
wa IC101 qa (XC-OUT)
– MC Board –
2.6 Vp-p
30.6
µ s
1.9 Vp-p
62.8
µ s
ea IC601 qs (MCLK2)
– DSP Board –
3.8 Vp-p
74
µ s
3.5 Vp-p
82 ns
ef IC601 w; (BCK0)
ed IC601 w; (LRCK0)
eg IC611 qd (LRCK)
eh IC611 qf (BCK)
ej IC611 qh (SYSCK)
ek IC603 wk (XOUT)
ra IC201 id (XO)
– GC Board –
3.4 Vp-p
20.8
µ s
3.3 Vp-p
326 ns
3.5 Vp-p
20.8
µ s
3.2 Vp-p
326 ns
3.5 Vp-p
82 ns
3.6 Vp-p
81
µ s
3.4 Vp-p
250 ns
