Sony HCD-FL3 - Printed Wiring Boards - CD DOOR Section

HCD-FL3
88
1-2. PRINTED WIRING BOARDS – CD DOOR Section –
• Semiconductor
Location
Ref. No. Location
D305 A-5
D341 A-2
D342 B-2
D343 B-2
D344 C-2
D345 C-2
IC302 A-5
3
1
IC302
CD DOOR BOARD CD MOTOR BOARD
CD DOOR SW1 BOARD
CD DOOR SW2 BOARD
CD DOOR
LOCK DETECT
1-684-205-
11
(13)
1-684-204-
11
(13)
S331
CD DOOR
OPEN/CLOSE
DETECT
1-684-202-
11
(13)
D
GC BOARD
CN206
2
1
2
CD DOOR
OPEN/CLOSE
M
91
1-684-203-
11
(13)
DISC 1
INDICATOR
DISC 2
INDICATOR
DISC 4
INDICATOR
DISC 5
INDICATOR
A
B
C
D
E
F
1 2 3 4 5 6 7
DISC 3
INDICATOR
ROTARY
ENCODER
VOLUME
123
R340
(Page 27)
