Sony HCD-FL3 - Printed Wiring Boards - TC DOOR Section

HCD-FL3
4444
8-15. PRINTED WIRING BOARDS – TC DOOR Section – • See page 35 for Circuit Boards Location.
TC DOOR BOARD
TC DOOR SW BOARD TC SW(A) BOARD
PM301
TC HOLDER
OPEN
(DECK A)
PM302
TC HOLDER
OPEN
(DECK B)
1-684-198-
11
(21)
1
2
12
6
V
GC BOARD
CN203
12
12
NO809B
1-684-200-
11
(21)
1-684-199-
11
(21)
A
S325
CASSETE LID
OPEN/CLOSE
DETECT
(Page 62)
