Sony HCD-FL3 - Printed Wiring Board - CENTER SW AMP Board

HCD-FL3
5656
8-26. PRINTED WIRING BOARD – CENTER SW AMP Board – • See page 35 for Circuit Boards Location.
D501 H-5
D502 G-5
D520 F-5
D521 G-7
D551 H-5
D552 G-7
D591 G-7
IC501 H-5
IC922 F2
Q501 G-5
Q521 H-8
Q522 H-8
Q523 G-7
Q551 G-7
• Semiconductor
Location
Ref. No. Location
IC501
123
112
IC922
CENTER SW AMP BOARD
M
DSP BOSRD
CN703
S
SP RELAY BOARD
CN804
1-684-262-
11
(21)
18
14
14
110
R
SP RELAY BOARD
CN803
EE
E
E
E
19
(CAASSIS)
A
B
C
D
E
F
G
H
1 2 3 4 5 6 7 8
D552
D502
Q
TRANS BOARD
CN916
(Page 49)
(Page 58) (Page 58)
(Page 70)
